CODAN SENTRY-H 6120-BM
by Codan | DTC
SKU 08-07403-001
Codan’s Sentry-H 6120-BM is designed for maximum reliability and efficiency and a wide range of DC input voltages for both military vehicle and base installations. The in-built power amplifier provides full-duty cycle performance across the complete HF band for all supported modes. The 6120-BM provides 150 W of power so that you get the best and most reliable communications, without the need for an external power amplifier. Whether you’re configuring a base or mobile system, the compact and highly integrated unit along with the robust handset makes for quick deployment.
Key features:
- Software Defined Radio
- 150 W power output (expandable to 500W/1kW)
- Wide range 10 V to 36 V DC input
- Rugged and waterproof MIL-STD810G design
- Rugged smart handset with colour display and integrated GPS
- Intuitive icon based colour display
- Multilingual user interface
- Embedded GPSIP/Ethernet/Wi-Fi/USB connectivityExceptional RF performance
- 2nd generation digital voice (TWELP)
- Digital voice message call
- Presets
- Standards based:
- MIL-STD-188-110A/B (STANAG 4539) Data (up to 19k2 bps)
- MIL-STD-188-110D (Appendix C)
- FED-STD-1045
- MIL-STD-188-141D (Appendix A, Appendix C)
- MIL-STD-188-141B ALE (JITC certified)
- 3G ALE (STANAG 4538)
- AES-256/CES-128 COMSEC
- ECCM - up to 25 hops/sec
- H-250 Accessories support
- Virtual Control Point (VCP) compatible
- Wide range of supported peripherals
